ZOS-T1608-02
ZOS-T1608-02 由红外发射二极管和 NPN 硅光晶体管组成，它们并排封装在黑色热塑性外壳中的汇聚光轴上。光电晶体管只接收来自 IR 的辐射。这是正常情况。但当物体在中间时，光电晶体管不能接收辐射。有关更多组件信息，请参阅IR 和 PT。
The ZOS-T1608-02 consist of an infrared emitting diode and an NPN silicon
phototransistor, encased side-by-side on converging optical axis in a black
thermoplastic housing.The phototransistor receives radiation from the IR only .This is the normal situation. But when an object is in between , phototransistor could not receives the
radiation.For additional component nformat on , please refer to IR and PT.
特性 Feature
--可靠性高、辐射强度高、低电压驱动
High reliability 、High radiant intensity 、Low forward voltage、
--感应速度快、感光度强
Fast response time 、High photo sen tivity
--截止感应波长 940nm
Cut-off visible wavelength λp=940nm
--无铅材料、Rohs 认证
Pb.Free 、RoHS compliant version
应用 Application
--打印机、非接触开关
-智能电子产品
--工业机械设备
--安防防护应用
